What we require from you…




green_earth (1).jpg


Certified Stamp.jpg


green-earth 4.jpg

green footprint.jpg

HERA LOGO trimmed.png


DRAWING REQUIREMENTS

Site plan

  • Showing all boundaries, adjoining properties and fences including heights

  • North point

  • Floor plan at each level

  • Elevations of all external walls

  • Section(s) with ground levels, floor and ceiling levels, bulkheads and roof levels

  • Window schedule if available (otherwise indicate on drawings)

  • All drawings must be to scale and clearly dimensioned



DRAWING INFORMATION

Floor

  • Floor construction (AAC/concrete slab on ground/suspended slab/timber)

  • Floor coverings (carpet/tiles/vinyl/none)

  • Floor insulation if applicable (reflective foil/bulk insulation)

Wall

  • External wall construction (brick veneer/cavity brick/FC/single brick/weatherboard)

  • Internal wall construction (brick/metal framed/timber framed)

  • Wall insulation proposed (reflective foil/bulk insulation)

Window

  • Window construction (aluminium/PVC/timber) and manufacturer if known

  • Window type (awning/casement/double hung/louvre/sliding)

  • Window glazing (double/single/reflective/tinted)

  • Show any proposed internal window coverings

  • Show any windows protected with external blinds, awnings, shutters or battens

  • Nominate whether doors/windows are weather-stripped and draught-proof

Roof

  • Roof construction (concrete/flat framed/metal/tiled)

  • Roof insulation if applicable

  • Ceiling insulation (bulk insulation)

Skylight and Roof Window

  • Show all skylights/roof lights and nominate if fixed/vented and/or shaded

  • Specify skylight/roof lights glazing type (single/double)

Ventilation

  • Show any chimneys and nominate whether sealed or unsealed

  • Show the location of any exhaust fans and nominate whether sealed or unsealed

  • Show all vented incandescent/fluorescent down lights

  • Show any ceiling fans and specify the proposed diameter

  • Reflected ceiling plan showing all artificial lighting – we can assist if not available
